Performance and design features:
Compact dual-piston rack and pinion mechanism, easy to install, high precision, long life, rotary output
Cold-drawn aluminum cylinder block, the inner surface of the hard texture, high strength, small friction coefficient
The adjusting screw of the cylinder positive standard products can be in the 0 ° and 90 °, two-position adjustable range of ± 4 °, to ensure that the synchronization accuracy of the valve
Precision rack and pinion, meshing accuracy, high efficiency
Integrated with leak-proof structure and bearing guide gear shaft, long life
Is05211 standard connection flange next convenient replacement and installation
The flat top of the output shaft easy manual operation
External are made of stainless steel copper fasteners
Using the multi spring preload design and applied epoxy coating, easy to dry interchangeable generic, increased security and anti-corrosion
Select high-quality bearings, excellent performance, low friction and high temperature
Operating conditions:
Operating medium: dry air containing corrosive gases or oils
Air source: dual action: 1 to 10 bar single action (BAR) :2-10 bar
Standard type (using nitrile rubber O-ring) -20 ° C - +80 ° C
-40 ° C - +80 ° C low temperature type (using a silicone rubber O-ring)
High temperature type (using Viton O-ring) -20 ° C - +150 seven
Lubrication: under normal operating conditions, without adding lubricant
Installation: Suitable for indoor or outdoor installation
Stroke Adjustment: 0 ℃ and 90 ℃ position i ± 4 ° adjustable range
|
